深圳市尚明光電有限公司
Shenzhen City Shinmi photoelectric Co.,Ltd




Switching power supply,AC to DC Power Supply,LED Power Supply,LED Power Manufact
  • AC to DC ,12w-400w
  • 瀏覽次數(shù):
  •
  • 產(chǎn)品介紹
  • Switching power supply,AC to DC Power Supply,LED Power Supply,LED Power Manufact



    AC input selectable by switch
    Protection: Overload /Over voltage/Over temperature/Short circuit
    LED power on indication
    100% full load burn-in test
    Built-in EMI filter
    1 year warranty
    MTBF>50,000 hours



    AC Input voltage range..............AC88V-132V/AC180-264V (selected by switch)
    Input frequency.........................47~63Hz
    DC voltage adjustment range......+10%
    Rise time..................................50ms@full load (typical)
    Hold up time.............................20ms@full load (typical)
    Operating temp. & humidity ........-20℃~+55℃, 20%~93%RH (non condensing)
    Storage temp. & humidity ...........-40℃~+85℃,10%~95%RH (non condensing)
    Cooling ......................................free air convention
    Withstand voltage.......................I/P-O/P: 1.5KVAC/IMIN
                                                    I/P-FG: 1.5KVAC/IMIN
                                                    O/P-FG: 0.5KVAC /1MIN
